Strong Corrosion Resistance Flexibility 100% 3K Customized Carbon Fiber Panel

Product Description

Strong Corrosion Resistance Flexibility 100% 3K Customized Carbon Fiber Panel

A customized carbon fiber panel is a flat, rigid structure made from carbon fiber reinforced polymer (CFRP) that is tailored to meet specific design requirements. These panels are designed and manufactured to fit precise dimensions, shapes, and performance specifications for a wide range of applications.

Key features of customized carbon fiber panels include:

• Tailored Design: Customized panels can be designed to meet specific size, shape, and performance requirements, allowing for a high degree of customization.
• Material Selection: Different types of carbon fiber fabrics, resin systems, and core materials can be selected based on the desired strength, stiffness, weight, and other properties of the panel.
• Manufacturing Process: Customized panels are typically manufactured using advanced techniques such as autoclave curing, resin infusion, or compression molding to achieve the desired properties and finish.
• Applications: Customized carbon fiber panels are used in a wide range of industries and applications, including aerospace, automotive, marine, sports equipment, and industrial machinery, where high-performance, lightweight materials are required.
• Quality Assurance: Customized panels are often subjected to rigorous quality control processes to ensure they meet the specified requirements and performance standards.

Overall, customized carbon fiber panels offer a high level of design flexibility and performance customization, making them an ideal choice for applications where off-the-shelf solutions do not meet the requirements.

Single-Sided Carbon Fiber Plate Specification:

FAQ:

1. What kind of finish is available for carbon fiber sheets? Are carbon fiber sheets with a matt finish available?

At this moment only carbon fiber sheets with a gloss finish are available. We can supply a matt finish for larger wholesale orders.

2. Do you supply carbon fiber sheets of thickness customized to individual needs? And what accuracy can your company guarantee?

Our standard carbon fiber sheets are manufactured with accuracy up to ~ + 0.2mm, which means that a sheet 1.5mm thick may have a thickness within the range of 1.5-1.7mm. Upon request, we provide cutting of carbon fiber sheets to the required thickness with an accuracy of 0.05mm.

3. Do you supply unidirectional carbon fiber sheets or biaxial and triaxial carbon fiber sheets?

We supply carbon fiber sheets with 2/2 (twill) or 1/1 (plain) weave but upon request, we also supply unidirectional carbon fiber (UD) or biaxial and triaxial carbon fiber sheets.

4. Are carbon fiber sheets of the quasi-isotropic type available?

We supply carbon fiber sheets with layers oriented at 0/90 degrees, but upon request, we also supply carbon fiber sheets with layers oriented at 0/90/-45/+45 degrees namely quasi-isotropic carbon fiber sheets.

5. What is the thermal resistance of carbon fiber sheets?

Carbon fiber sheets offer thermal resistance of up to 70oC. Upon request, we also supply carbon fiber sheets with thermal resistance up to 150oC.

6. How can I cut carbon fiber sheets in my workshop?

The carbon fiber plates we make are easy to process. They do not flatten when milling on a CNC machine, and the edges are sharp and nice. The carbon plates we make can also be easily machined with household tools such as an angle grinder, drill, file, sandpaper, etc.

7. Can carbon fiber sheets be painted?

Actually, any further treatment depends on the intended use. All supplied carbon fiber sheets (and ones made from epoxy resin) offer resistance to UV. However in the case of long duration or repeated exposure to sunshine (UV radiation) it is recommended to apply a layer of clear top coat (e.g. Polyurethane and Acrylic based) on the outer side of the carbon fiber sheet to ensure total protection against UV radiation.
