100X250X0.3MM 100% 3K Carbon Fiber Plate Plain Weave Panel Sheet 0.3mm Thickness (Glossy Surface)

Product Description

100X250X0.3MM 100% 3K Carbon Fiber Plate Plain Weave Panel Sheet 0.3mm Thickness (Glossy Surface)

A carbon fiber sheet that is 0.3mm thick is an extremely thin and lightweight material. Despite its thinness, it retains the strength and stiffness properties that carbon fiber is known for, making it ideal for applications where weight savings and strength are critical.

These ultra-thin carbon fiber sheets are often used in industries such as aerospace, automotive, and robotics, where lightweight materials are essential. They can be used for a variety of purposes, including reinforcing parts, creating lightweight structures, and providing a decorative finish.

Due to their thinness, these sheets are flexible and can be easily cut and shaped to fit specific applications. They are also compatible with a variety of resin systems, allowing for customization of properties such as stiffness, strength, and surface finish.

Product Description: This carcon fiber sheets contains 100% carbon fiber imported from Japan.

The surface is plain weave, glossy surface without any glass fiber contents. It is specially applicable for multicopter, helicopter and rc airplanes.

• Item Name: Full Carbon Fiber Sheets
• Dimension: 100mm x 250mm x 0.3mm
• Thickness: 0.3mm
• Surface: 3K, Plain Weave, Glossy Surface
• Features: b Strength and Light Weight

Advantages:

• ​100% real carbon fiber prepreg sheets
• Light weight and high-strength
• High performance-without pin holes
• High glossy-mirror like

Single-Sided Carbon Fiber Plate Specification:

FAQ:

1. What kind of finish is available for carbon fiber sheets? Are carbon fiber sheets with a matt finish available?

At this moment only carbon fiber sheets with a gloss finish are available. We can supply a matt finish for larger wholesale orders.

2. Do you supply carbon fiber sheets of thickness customized to individual needs? And what accuracy can your company guarantee?

Our standard carbon fiber sheets are manufactured with accuracy up to ~ + 0.2mm, which means that a sheet 1.5mm thick may have a thickness within the range of 1.5-1.7mm. Upon request, we provide cutting of carbon fiber sheets to the required thickness with an accuracy of 0.05mm.

3. Do you supply unidirectional carbon fiber sheets or biaxial and triaxial carbon fiber sheets?

We supply carbon fiber sheets with 2/2 (twill) or 1/1 (plain) weave but upon request, we also supply unidirectional carbon fiber (UD) or biaxial and triaxial carbon fiber sheets.

4. Are carbon fiber sheets of the quasi-isotropic type available?

We supply carbon fiber sheets with layers oriented at 0/90 degrees, but upon request, we also supply carbon fiber sheets with layers oriented at 0/90/-45/+45 degrees namely quasi-isotropic carbon fiber sheets.

5. What is the thermal resistance of carbon fiber sheets?

Carbon fiber sheets offer thermal resistance of up to 70oC. Upon request, we also supply carbon fiber sheets with thermal resistance up to 150oC.

6. How can I cut carbon fiber sheets in my workshop?

The carbon fiber plates we make are easy to process. They do not flatten when milling on a CNC machine, and the edges are sharp and nice. The carbon plates we make can also be easily machined with household tools such as an angle grinder, drill, file, sandpaper, etc.

7. Can carbon fiber sheets be painted?

Actually, any further treatment depends on the intended use. All supplied carbon fiber sheets (and ones made from epoxy resin) offer resistance to UV. However in the case of long duration or repeated exposure to sunshine (UV radiation) it is recommended to apply a layer of clear top coat (e.g. Polyurethane and Acrylic based) on the outer side of the carbon fiber sheet to ensure total protection against UV radiation.
