0.5mm - 12mm Thickness 3K Carbon Fiber Plate Laminate Twill Weave Panel Sheets

Product Description

Laminate Twill Weave Panel Sheets 0.5mm-12mm Thickness 3K Carbon Fiber Plate

LIJIN Carbon Fiber is known for its extremely high quality, durability, and beautiful finish. Now you can cut your own parts out of the exact same carbon fiber that is used in popular airframes. Each carbon fiber sheet goes through a meticulous QC process ensuring that there are no flaws in any sheet that is sold.

These high-quality carbon fiber sheets come in various thicknesses, are made from 100%, 3K plain weave, and carbon fiber, and are finished with a matte surface on both sides. Unlike many low-cost carbon sheets that are made by pressing two outer skins of carbon fiber over a carbon and resin core, these plates are made with layered sheets of carbon fiber and resin, making them the same strength all the way through.

Main Features:

• 100% Real Carbon Fiber - High-quality 3K carbon fiber imported from Japan, which has high tensile strength, corrosion resistance, and impact resistance, and is not easy to tear.
• Twill Weave - This carbon fiber is a twill weave with a matte surface that conforms more easily.
• Wide Application - Accessories for RC drone frames, airplanes, kites, car decorations, cellphones, laptops, wallets, medical equipment etc.

For model making, car Interior styling etc. very light and strong. 3K Twill Weave, Matte surface on both sides. 100% Carbon Fibre sheet: hot pressed 3K Carbon Fibre. Twill weave, Matte finish Carbon Fibre Fabric on both sides.

Carbon fibre sheet is very strong owing to its perfect ratio of reinforcement to matrix and pressure consolidation during curing and is manufactured to engineering tolerances.

These high-quality carbon fiber sheets come in various thicknesses, are made from 100%, 3K woven carbon fiber, and are finished with a glossy surface on both sides. Carbon fiber is used in industries where high strength and rigidity are required in relation to weight. e.g. in drone frames, car chassis, aviation, automated machines, racing cars, professional bicycles, etc.

Single-Sided Carbon Fiber Plate Specification:

FAQ:

1. What kind of finish is available for carbon fiber sheets? Are carbon fiber sheets with a matt finish available?

At this moment only carbon fiber sheets with a gloss finish are available. We can supply a matt finish for larger wholesale orders.

2. Do you supply carbon fiber sheets of thickness customized to individual needs? And what accuracy can your company guarantee?

Our standard carbon fiber sheets are manufactured with accuracy up to ~ + 0.2mm, which means that a sheet 1.5mm thick may have a thickness within the range of 1.5-1.7mm. Upon request, we provide cutting of carbon fiber sheets to the required thickness with an accuracy of 0.05mm.

3. Do you supply unidirectional carbon fiber sheets or biaxial and triaxial carbon fiber sheets?

We supply carbon fiber sheets with 2/2 (twill) or 1/1 (plain) weave but upon request, we also supply unidirectional carbon fiber (UD) or biaxial and triaxial carbon fiber sheets.

4. Are carbon fiber sheets of the quasi-isotropic type available?

We supply carbon fiber sheets with layers oriented at 0/90 degrees, but upon request, we also supply carbon fiber sheets with layers oriented at 0/90/-45/+45 degrees namely quasi-isotropic carbon fiber sheets.

5. What is the thermal resistance of carbon fiber sheets?

Carbon fiber sheets offer thermal resistance of up to 70oC. Upon request, we also supply carbon fiber sheets with thermal resistance up to 150oC.

6. How can I cut carbon fiber sheets in my workshop?

The carbon fiber plates we make are easy to process. They do not flatten when milling on a CNC machine, and the edges are sharp and nice. The carbon plates we make can also be easily machined with household tools such as an angle grinder, drill, file, sandpaper, etc.

7. Can carbon fiber sheets be painted?

Actually, any further treatment depends on the intended use. All supplied carbon fiber sheets (and ones made from epoxy resin) offer resistance to UV. However in the case of long duration or repeated exposure to sunshine (UV radiation) it is recommended to apply a layer of clear top coat (e.g. Polyurethane and Acrylic based) on the outer side of the carbon fiber sheet to ensure total protection against UV radiation.
