3K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Normal Corrugated Carton Packing for International Shipment Delivery Time : 7 working days after receiving Order Pay
Payment Terms : T/T, Western Union, L/C Supply Ability : 1500pcs month
Place of Origin: China Brand Name: Tanku
Certification: SGS, ROHS Model Number: OEM

Detail Information

Product Name: 3K CF Tube Carbon Fiber Material Description: 100% Carbon Fiber
Pattern: Twill, Plain Length: 1000MM
Technology: Roll-wrapped Weaves: 3K Plain / 3K Twill / Unidirection
Density: 1.5g/cm^3 Fibre Orientation: 0, 90
High Light:

40x38x1000mm CF Tube

,

3K Roll Wrapped CF Tube

,

Twill Matte Finish Carbon Fiber Tube

Product Description

40x38x1000mm 3K CF Tube Carbon Fiber / Fibre Tube 3K Roll Wrapped


This 3K Woven Finish tube is manufactured from alternating layers of unidirectional prepreg carbon fibre for maximum strength with the final layer swapped for 2/2 twill, 3K woven carbon fibre so that the tube has the classic appearance of woven carbon fibre. This means that although the tubes are designed for demanding mechanical applications, they also look fantastic, adding a cutting-edge carbon fibre appearance to any application.



SPECIFICATIONS:

  • Outer Diameter: 40MM | Inner Diameter: 38MM
  • Wall Thickness: 1MM
  • Length: 1000MM
  • Weight: — g
  • Material: 3K Roll Wrapped Carbon Fiber Twill Matte Finish

APPLICATIONS:



This tube is ideally suited to a wide range of applications such as radio-controlled models (RC Planes), UAVs, Drones, Multicopters, recreational equipment, sporting goods, robotics, and photography/video equipment (tripods, etc.).



Technical Characteristics


1. High strength and high efficiency.


The tensile strength is several times higher than that of ordinary steel, and its elastic modulus is better than that of steel. It has excellent creep resistance, corrosion resistance, and shock resistance.



2. Light weight and good flexibility.


Carbon fiber tube has high strength, the quality is only 1×5 of steel, has high toughness, can be coiled, and can be supplied at a larger length without a lap connection.



3. The construction is convenient and the construction quality is easy to be guaranteed.


The material does not need pre-processing, the working procedure is convenient, and the plate is allowed to cross.



4. Good durability and corrosion resistance.


It is resistant to acid, alkali, salt, and atmospheric environment, and does not need regular maintenance.



5. With electrical conductivity.


Pay special attention to electricity prevention when using.



Material 3K CF Tube Carbon Fiber
Shape Round
Technology Roll-wrapped or pultrusion
Dimension The existing inner diameter of the mold is 4mm-50mm with a length of 1m.
Customizable size: The maximum diameter can be 200mm, the longest can be 3m.
Surface Black glossy/matte surface/painted
Glossy 3k weave/matte 3k weave
Color metal wire weave
Feature lightweight, high strength
Working Temperature Usually, -30-120 degrees, if special requirement, please let us know.
Place Of Origin China
Function Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products
Tolerance Diameter Tolerance: +/-0.1mm
Length Tolerance +/-1mm


Our Service:

1. It ensures that a year of quality assurance and 24 hours online customer service.
2. Protection of your sales area, ideas of design, and all your private information.
3. Request for samples is accepted.
4. Drilling and slotting are accepted.
5. We guarantee the products to be manufactured with the finest materials and mature technics.
All tubes can be repaired at no charge if returned to us, postage prepaid, within one year.


3K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube 03K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube 13K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube 23K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube 33K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube 4
