100% Customized Size Carbon Fiber Round Tubes Abrasion Resistant
Contact Person : Terry.Chang, Annie.Liang
Phone Number : +86-13681832139
WhatsApp : +8619537611058
Minimum Order Quantity : | Negotiable | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Normal Corrugated Carton Packing for International Shipment | Delivery Time : | 7 working days after receiving Order Pay |
Payment Terms : | T/T, Western Union, L/C | Supply Ability : | 1500pcs month |
Place of Origin: | China | Brand Name: | Tanku |
---|---|---|---|
Certification: | SGS, ROHS | Model Number: | OEM |
Detail Information |
|||
Product Name: | Woven Finish Carbon Fibre Tube | Shape: | Round/Rectangular/etc. |
---|---|---|---|
Pattern: | 3K Twill, Accept 1K, 2K, 4K, 5K, Etc | Production Process: | Roll-Wrapped |
Fiber Type: | Standard Modulus Carbon Fiber | Tensile Strength: | 1600Mpa |
Fiber Orientation: | 0, 0/90, ±45degree | Surface: | High Gloss Epoxy |
High Light: | Woven Roll Wrapped Carbon Fiber Tubes,High Gloss Epoxy Carbon Fiber Tubes,3k Carbon Fiber Pipes |
Product Description
Engineering-Grade Durable Woven Finish Roll Wrapped Carbon Fibre Tubes
At LIJIN we pride ourselves on our huge range of engineering-grade carbon fibre tubes which includes these great-looking woven finish roll-wrapped carbon fibre tubes. Tubes in this range are manufactured using the roll-wrapping process using 100% high-strength carbon fibre reinforcement for excellent 'real-world' multi-axis strength but they are finished with an attractive 2x2 twill carbon fabric for that classic carbon fibre appearance resulting in tubes that look as good as they perform. These tubes are suitable for a wide range of applications including UAVs, quad-copters, aero-modeling, camera rigs, tripods, automation, leisure equipment, motor-sport, and much more.
Roll-wrapped carbon fibre tubes are manufactured by wrapping multiple layers of prepreg carbon fibre reinforcement around a metal mandrel which is wrapped with shrink tape and cured at high temperature. Because the reinforcement is wrapped in layers around the mandrel, it is possible to alternate the alignment of the carbon fibre between layers, enabling roll-wrapped tubes to have longitudinal stiffness down their length, as well as strength in the 'hoop' direction, making them more resilient to crush, burst and torsional fracture. We have a video tutorial demonstrating the roll-wrapping process here.
This round tubing is comprised of Carbon Fiber Braid and Unidirectional Fabrics. This product is ideal for building lightweight frames and structures such as trusses. Our Carbon Fiber square tubing has been engineered to be much stronger under torsional and side loading than pultruded tubing.
Our tubing is also significantly lighter than pultruded tubing. Our carbon fiber square tube has been designed so that the unidirectional layers are captured in a sandwich structure, eliminating longitudinal cracking and splitting. The finish on this product is different from our other product lines. These square tubes show the texture of the carbon fiber braid with a wet shiny appearance.
Material | Woven Finish Carbon Fibre Tube |
Shape | Round/Oval |
Technology | Roll-wrapped or pultrusion |
Dimension | The existing inner diameter of the mold is 4mm-50mm with a length of 1m. |
Customizable size: The maximum diameter can be 200mm, the longest can be 3m. | |
Surface | Black glossy/matte surface/painted |
Glossy 3k weave/matte 3k weave | |
Color metal wire weave | |
Feature | lightweight, high strength |
Working Temperature | Usually, -30-120 degrees, if special requirement, please let us know. |
Place Of Origin | China |
Function | Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products |
Tolerance | Diameter Tolerance: +/-0.1mm |
Length Tolerance | +/-1mm |
