Glossy Surface3K Full Carbon Fiber Tube High Strength Length 500mm OD 10mm 15mm

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Normal Corrugated Carton Packing for International Shipment Delivery Time : 7 working days after receiving Order Pay
Payment Terms : T/T, Western Union, L/C Supply Ability : 1500pcs month
Place of Origin: China Brand Name: Tanku
Certification: SGS, ROHS Model Number: OEM

Detail Information

Features: Lightweight, High Strength Product Name: 3K Full Carbon Fiber Tube
Material Description: 100% Carbon Fiber Pattern: Twill, Plain
Shape: Round Or Custom Technology: Roll-wrapped
Weaves: 3K Plain / 3K Twill / Unidirection Density: 1.5g/cm^3
Fibre Orientation: 0, 90 Application: Aerospace,RC Model Parts, Industial Automation And Robotics
High Light:

3K Full Carbon Fiber Tubing

,

Glossy Surface Carbon Fiber Round Tube

,

OD 10mm Carbon Fiber Rod

Product Description

3K Full Carbon Fiber Tube High Strength Length 500mm OD 10mm 15mm 20mm 22mm 25mm 30mm Glossy Surface



Composite carbon tubes and carbon rods are made by pulling carbon fibers through a resin (vinylester or epoxy) bath and a series of dies and ovens to create composites rods or tubes with all fibers oriented in one direction, longitudinally. Strong, durable, and lightweight, carbon rods and tubes are an ideal material for structural components. Our customers use carbon fiber rods and carbon fiber tubes in aerospace applications, cargo and surveillance blimps, aircraft wing spars, as rollers and other structural pieces in industrial machinery, in guitar necks, as push rods and tail booms in model airplanes and helicopters, and much more.



Our vast catalog of carbon rods and tubes offers off-the-shelf solutions for replacing parts in your project or prototyping your design with carbon composites.



We supply the carbon fiber tubes in various specifications and color.



The main benefits of carbon fiber over typically used metal tubing are as follows:

• Light Weight(low density)
• High Strength
• High Stiffness
• Chemical resistant
• Low Coefficient of Thermal Expansion
• Good surface



The main techniques we use are pultrusion and table rolling. With rich experience on pultrusion and FRP, we can provide you with varieties of tubes with different length and wall thickness.



LIJIN manufactures custom carbon fiber pultrusions to fit your strength, stiffness, and geometric requirements. Our products can be used as fishing poles, paddles, arrow shafts, alpenstocks, etc.



The regular color is black. And other colors are also available by special request.



To get more information or have an inquiry, please feel free to contact us.



Material 3K Full Carbon Fiber Tube
Shape Round/Oval
Technology Roll-wrapped or pultrusion
Dimension The existing inner diameter of the mold is 4mm-50mm with a length of 1m.
Customizable size: The maximum diameter can be 200mm, the longest can be 3m.
Surface Black glossy/matte surface/painted
Glossy 3k weave/matte 3k weave
Color metal wire weave
Feature lightweight, high strength
Working Temperature Usually, -30-120 degrees, if special requirement, please let us know.
Place Of Origin China
Function Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products
Tolerance Diameter Tolerance: +/-0.1mm
Length Tolerance +/-1mm


Our Service:

1. It ensures that a year of quality assurance and 24 hours online customer service.
2. Protection of your sales area, ideas of design, and all your private information.
3. Request for samples is accepted.
4. Drilling and slotting are accepted.
5. We guarantee the products to be manufactured with the finest materials and mature technics.
All tubes can be repaired at no charge if returned to us, postage prepaid, within one year.
