980 X 480 X 2mm Plain Carbon Epoxy Panel Double Sides High Gloss Finish

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Normal Corrugated Carton Packing for International Shipment Delivery Time : 7 working days after receiving Order Payment
Payment Terms : T/T, PayPal,Western Union , L/C Supply Ability : 1500pcs month
Place of Origin: China Brand Name: Tanku
Certification: SGS, ROHS Model Number: TM_340mm_410mm_2.5mm

Detail Information

Features: Very Strong And Light Product Name: Carbon Fiber Panel
Surface Weave: Plain/Twill Material: Carbon Fiber
Color: Black Skin Layer: 3K
Surface Finishing: Matte/Gloss Standard Thickness: 0.3mm, 0.5mm, 1mm, 2mm, 3mm, Etc.
Applications: Robotics, RC Models, UAVs, Aerospace, Motorsports, Marine Applications, Musical Instruments Etc. Port: Shanghai
High Light:

Double Sides Plain Carbon Fiber Board

,

High Gloss Finish Carbon Epoxy Panel

,

Epoxy Carbon Fiber Board

Product Description

Carbon Fiber/Epoxy Panel 980x480x2mm, surface high gloss finish on both sides



These high quality carbon fiber sheets come in various sizes, made from 100%, 3K plain weave, carbon fiber and finished with a matt surface on both sides. Unlike many low cost carbon sheets that are made by pressing two outer skins of carbon fibre over a carbon and resin core, these plates are made with layered sheets of carbon fibre and resin, making them the same strength all the way through.



Whether you're making your own drone frames, car chassis, firewalls, bulkheads or any other custom designs that require high strength, lightweight material, these quality carbon fiber sheets are more than up to the task.



The characteristic of plain weave is that the warp and weft are interwoven in a regular pattern, that is, the warp and weft are interlaced every other yarn, so there are many interweaving points, and the fabric is firm, wear-resistant, stiff and flat.



Our high-gloss carbon fiber sheets are made of 100% genuine carbon fiber, using a 2x2 twill weave fabric. One side of the carbon fiber sheet carries a mirror-like high gloss finish, while the back is pre-textured to bond to any surface, using the optional 3M high-performance double-sided adhesive (arrives unattached). The finish is perfect for high-end decorative applications. Please see below for more information on each carbon fiber sheets thickness to better understand what makes sense for your application.



Features:

  • Performance: flat appearance, no bubbles and other defects, high temperature resistance, acid and alkali salt resistance and atmospheric environment corrosion resistance, high hardness, high impact strength, no creep, high modulus, low density and low linear expansion coefficient.
  • Process: multi layer carbon fiber cloth is pre-impregnated with imported epoxy resin and then laminated at high temperature.
  • 3k, 12K carbon fiber, plain / twill, bright / matte,
  • Application: UAV model, aircraft, medical CT bed board, X-ray filter grid, rail transit parts and other sporting goods, etc.

Our company produces carbon fiber board with high resistance of 200 ℃ – 1000 ℃, which can continue to maintain its physical properties in the environment with gradually rising temperature. Its flame retardant level is 94-V0, which can achieve high standard results without deformation


Thickness 0.3-6.0mm can be customized. please feel free to contact us if you have any interests.



Single-Sided Carbon Fiber Plate Specification:



Item Name

Thickness

Length & Width

Weave

Finish

SKU Code

N.W.

Regular MOQ

1st Order MOQ

Ship From

05005060, Full CF Plate, Plain Weave,6K, Matte, TT

5

500mm*600mm

Twill

Glossy

TG05005060PLTFCF3KTT

2.48

5

1

China factory

04005060, Full CF Plate, Plain Weave,5K, Matte, TT

4

500mm*600mm

Twill

Glossy

TG04005060PLTFCF3KTT

1.94

5

1

China factory

03005060, Full CF Plate, Plain Weave,4K, Matte, TT

3

500mm*600mm

Twill

Glossy

TG03005060PLTFCF3KTT

1.46

5

1

China factory

02505060, Full CF Plate, Plain Weave,3K, Matte, TT

2.5

500mm*600mm

Twill

Glossy

TG02505060PLTFCF3KTT

0

5

1

China factory

02005060, Full CF Plate, Plain Weave,3K, Matte, TT

2

500mm*600mm

Twill

Glossy

TG02005060PLTFCF3KTT

0.96

5

1

China factory

01505060, Full CF Plate, Plain Weave,3K, Matte, TT

1.5

500mm*600mm

Twill

Glossy

TG01505060PLTFCF3KTT

0.73

5

1

China factory

01005060, Full CF Plate, Plain Weave,3K, Matte, TT

1

500mm*600mm

Twill

Glossy

TG01005060PLTFCF3KTT

0.53

5

1

China factory



FAQ:



1. Are you a factory or a trading?

We are a factory, with more than 16 years experience in composite products. We are one of the top manufacturers of carbon fiber tubes in China.



2. Can you send us a sample to check?

Yes, we can send you a free sample to check. You can pay the freight costs. When you place an order, we will return the freight cost to you.



3. What about the terms of payment?

T/T, L/C, Western union, etc



4. When can I get the quotation?

We usually quote within 24 hours after we get your inquiry.



5. What’s the difference between Chengcheng and other factories?

We have our own technology and research team. Our products strictly follow the quality control system in the composite products field.



6. Do you provide OEM service

Yes. OEM is welcome. We can make molds according to customers’ drawings and samples
