3K Roll Wrapped Carbon Fiber Tube 40 X 38 X 1000mm CF Tube
Contact Person : Terry.Chang, Annie.Liang
Phone Number : +86-13681832139
WhatsApp : +8619537611058
|Minimum Order Quantity :||Negotiable||Price :||Negotiable|
|Packaging Details :||Normal Corrugated Carton Packing for International Shipment||Delivery Time :||7 working days after receiving Order Pay|
|Payment Terms :||T/T, Western Union, L/C||Supply Ability :||1500pcs month|
|Place of Origin:||China||Brand Name:||Tanku|
|Certification:||SGS, ROHS||Model Number:||OEM|
|Product Name:||8MM Carbon Fiber Tube||Outside Diameter:||8.0 Mm|
|Ultimate Tensile Strength:||1600-2300 MPa||Resin Glass Transition Tg:||170º C|
High Strength 8mm Carbon Fiber Rod,
UV Resistant 8mm Carbon Fiber Rod,
8mm OD Carbon Fiber Tube
High Strength and Light Weight 8MM Carbon Fiber Tube - UV Resistant
Pultruded carbon fiber tubes and rods offer extremely high strength and stiffness because they contain 95% unidirectional carbon fiber running longitudinally. Pultruded tubes are ideal for scale aircraft, gliders, helicopters or any construction that requires strength, rigidity and lightness.
8.0 mm diameter high modulus carbon fiber tube available in various lengths. These pultruded tubes have a high fibre content of high modulus carbon fiber in an epoxy matrix, making them extremely rigid and strong.
These Carbon Fiber TUBES are great for reinforcing models or other arts and crafts. Use them in the wings, fuselage, or other parts of the model.
Round carbon fibre tube manufactured by using the pultrusion technique in which the high-performance carbon fibres are all orientated parallel to the longitudinal axis (unidirectional) and internally reinforced with more unidirectional carbon fibres laminated by using pullwingding technology to achieve greater resistance to bending and torsion.
This type of profile has a high specific mechanical resistance (related to its weight), lightness, rigidity, great resistance to fatigue and vibrations, resistance to oxidation and corrosion, low coefficient of thermal expansion and durability.
Pultrusion is a technique of continuous production of linear profiles with a constant section. This process has many similarities to extrusion, the main difference is in the feeding system: in extrusion the material is pushed through the matrix (mould), in pultrusion it is extracted from the matrix. This procedure does not allow variations in shape, sections or curves. Products that can be obtained by this process can have sections or thicknesses of up to approximately 15mm, with epoxy resins and up to 70mm with polyester resins.
Products made with this technology have excellent tensile strength characteristics due to the linear orientation of the fibres in the direction of axis of the profile; if it is also necessary to have a good transversal resistence, a woven fabric is used as a backing in specific quantities and weights.
|Material||8MM Carbon Fiber Tube|
|Technology||Roll-wrapped or pultrusion|
|Dimension||The existing inner diameter of the mold is 4mm-50mm with a length of 1m.|
|Customizable size: The maximum diameter can be 200mm, the longest can be 3m.|
|Surface||Black glossy/matte surface/painted|
|Glossy 3k weave/matte 3k weave|
|Color metal wire weave|
|Feature||lightweight, high strength|
|Working Temperature||Usually, -30-120 degrees, if special requirement, please let us know.|
|Place Of Origin||China|
|Function||Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products|
|Tolerance||Diameter Tolerance: +/-0.1mm|
1. It ensures that a year of quality assurance and 24 hours online customer service.
2. Protection of your sales area, ideas of design, and all your private information.
3. Request for samples is accepted.
4. Drilling and slotting are accepted.
5. We guarantee the products to be manufactured with the finest materials and mature technics.
All tubes can be repaired at no charge if returned to us, postage prepaid, within one year.
1. Can you produce according to the samples or drawings?
Yes, we can produce your samples or technical drawings. We can create the molds and fixtures.
2. What are your terms of payment?
Usually, we accept T/T, irrevocable L/C at sight. For regular orders, Terms of payment 30% deposit, balance before shipment.
3. What is the lead time?
It usually takes 25 to 35 days after sample confirmation and receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
4. What are your terms of packing?
Generally, we pack our goods in neutral cartons. It is fragile we will make the wooden frame. and we also can according to your requirements.
5. What are your terms of delivery?
We accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or cost-effective for you.
6. How to solve the quality problems after sales?
Take photos of the problems and send them to us. We will make a satisfied solution for you within 24 hours after we confirm the problems.
7. Is it OK to print my logo on carbon fiber products?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
8. You are a manufacturer or trading company?
We are a factory. Welcome to visit our factory at any time.
