Rolled wrapping Carbon Fiber Telescope Tube 5000mm For Automation Robotics

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Normal Corrugated Carton Packing for International Shipment Delivery Time : 7 working days after receiving Order Pay
Payment Terms : T/T, Western Union, L/C Supply Ability : 1500pcs month
Place of Origin: China Brand Name: Tanku
Certification: SGS, ROHS Model Number: OEM

Detail Information

Product Name: Custom Carbon Fibre Tube Material: 100% Carbon Fiber
Color: Black Or Any Color Size: Any Size Make-to-Order
Technology: Rolled-wrapping Shape: Round, Square, Oval Or Per Your Request
Surface: Natural, 3K Woven, Glossy Or Matte Pattern: Twill, Plain
Length: Blow 5000mm Application: Cleaning Equipment, Automation Robotics, Telescoping Poles, Etc.
High Light:

3K Rolled Wrapping Carbon Fiber Tube

,

Carbon Fiber Telescope Tube 5000mm

,

Automation Robotics Carbon Fiber Tube

Product Description

Excellent Structural Performance Best Standard Custom Carbon Fibre Tube



The majority of composite tubing we supply to customers is custom-made following design consultations. However, we do stock a large range of standard carbon fibre tubing which may meet our customer's needs.



Our standard round carbon fibre tubes are constructed with a full carbon laminate which has been optimized to give the tubes very high strength and stiffness in bending, tension, and/or compression. They are finished with a woven 3k twill.



LIJIN also makes other non-circular composite profiles including ovals, hexagons, etc. We design and make our carbon fiber tubes to your specification so please contact us with your requirements.



9 ways we can serve you better than our competition

  1. We offer a high-quality product on a consistent basis.
  2. We guarantee that every tube will be within the tolerances given. We don't do spot checking here, every single tube gets measured and visually inspected for defects before it leaves our shop.
  3. Single tube minimum on custom tubes.
  4. Wide selection of proprietary tooling.
  5. We have over 100 mandrel sizes between zero and four inches. If we own it you can use it.
  6. No minimum charge for custom tubes
  7. The only price of entry for our services is the price of the tubes themselves. $5-20K minimums are not uncommon in our industry.
  8. Fair tube pricing
  9. We will offer you a reasonable price with volume discounts for tubes.

For several years, LIJIN Composites has supplied customers with custom carbon fiber tubes. Depending on the application, sizes have ranged from smaller 6 and 8-inch tubes to ones greater than 40 inches. Our current manufacturing processes allow the fabrication of custom carbon fiber tubes up to 48 inches in diameter. These small and large diameter carbon fiber tubes offer great versatility, both in material selection and layup schedule. Typical reinforcement materials include carbon fiber, fiberglass, and aramid fibers. In addition, core materials can be added between the high-strength skins, creating a sandwich structure. Many of the materials available for flat plate sandwich cores can also be used when producing sandwich core walls for custom tubes, with the most common examples being honeycomb and thermoformable form. Each custom carbon fiber tube construction method has specific advantages: pure laminate composite tubes result in thin walls that retain the mechanical, thermal, and electrical properties of the fiber, while sandwich core walls provide a lightweight means to increase local wall stiffness.



Given the wide variety of choices available for small and large diameter carbon fiber tubes, the selection of materials and layup schedule often come from the project requirements. A good example telescopes, where the low thermal expansion of solid or sandwich core carbon fiber tubes provides substantial improvements over metal tubes, thus offering the astronomer more reliability with temperature change. Another example is the fabrication of radomes, which often use solid fiberglass or foam-filled fiberglass sandwich construction. A third example is in the creation of high-quality drums, where the material and layup direction can be optimized for both resonances and acoustic damping. One final example is pressure vessels, which require thicker walls with adequate resistance to the high hoop stresses present in these applications.

Regardless of the application, the engineers at LIJINwould be more than happy to discuss your specific application and how we may be able to help. We look forward to helping you develop a custom carbon fiber tube for your upcoming project’s needs.



Name Carbon Fiber Round Tube/Square Carbon Fiber Tube
Feature 1. Made of high modulus 100% carbon fiber imported from Japan with epoxy resin
2. Great replacement for the low-grade aluminum wing tubes
3. Weights only 1/5 of steel and 5 times stronger than steel
4. Low Coefficiency Of Thermal Expansion, High-Temperature Resistance
5. Good Tenacity, Good Toughness, Low Coefficiency Of Thermal Expansion
Specification Pattern Twill, Plain
Surface Glossy, Matte
Line 3K Or 1K,1.5K, 6K
Color Black, Gold, Silver, Red, Bue, Gree(Or With Color Silk)
Material Japan Toray Carbon Fiber Fabric+Resin
Carbon Content 68%
Size Type ID Wall thickness Length
Round Tube 6-60 mm 0.5,0.75,1/1.5,2,3,4 mm 1000,1200,1500 mm
Square Tube 8-38 mm 2,3 mm 500,600,780 mm
Application 1. Aerospace, Helicopters Model Drone, UAV, FPV, RC Model Parts
2. Manufacture Fixtures And Tooling, Industrial Automation
3. Sports Equipment, Musical Instruments, Medical Device
4. Building Construction Repair And Strengthening
5. Car Interior Decoration Parts, Art Products
6. Others
Packing 3 layers of protective packaging: plastic film, bubble wrap, carton
(Normal size: 0.1 * 0.1 * 1 meter(width*height*length)



Uses Include:

  • Aerospace Spars & Beams
  • UAV Housing Components
  • Frames & Supports
  • Structural Components
  • Interior Design
  • Automation Equipment
  • Recreational Equipment
Our advantages:
  • Good production capacity, prompt delivery
  • The specification can be customized
  • Strict quality control system in every production process
  • 24 hours service, quick reply
  • Small order accepted
  • Perfect after-sales service, free sample is available
  • Customized Service

Frequently Asked Questions About Carbon Fiber Tubes



1. What’s the feature of your product?

There are many good characteristics of our carbon fiber product, such as lightweight, high strength, durable, and fashion, etc.



2. Can I have a sample order?

Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. For some products, we can offer free samples. Clients just need to bear the shipping cost.



3. What is the lead time?

The sample needs 1-3 days, mass production depends on order quantity. Normally 6-9 days.



4. Can you accept the mixed batch of different products?

Yes, we are support different product mix wholesale, no limit of raw materials and mechanical parts, and color specifications, etc.



5. What file need if need to do CNC Cutting or molding products?

We Need CAD DXF or DWG files for CNC cutting, 3D, STEP, STP, IGS Files for molding.



6. How do we do quality control?

We have inspectors to check each procedure to avoid any mistakes.



7. How do you pack the goods?

We wrap the goods with soft plastic bags first and then pack them using a cardboard box with foam board inside.



8. How is your after-sale service?

We provide our clients with excellent after-sale service including logistics tracking, application guide, problem solution,
