Strong and Lightweight 100% 3K Roll Wrapped Carbon Telescopic Tube
Contact Person : Terry.Chang, Grace Gu
Phone Number : +86-13681832139
WhatsApp : +8619537611058
Minimum Order Quantity : | 10 Sets | Price : | Negotiable |
---|---|---|---|
Packaging Details : | 150*30*30cm/CTN, 10 Sets/CTN, Corrugated Carton for International Ocean Airlines shipping | Delivery Time : | 25 Days after Order Confirmation |
Payment Terms : | L/C, T/T, PayPal | Supply Ability : | 500 Sets/Month |
Place of Origin: | China | Brand Name: | 10M |
---|---|---|---|
Certification: | SGS | Model Number: | 10M45FT |
Detail Information |
|||
Features: | Eco-friendly, High Strength, Lighter Weight, Against The Wind | Keyword: | Carbon Fiber Telescopic Pole |
---|---|---|---|
Surface: | UD Surface Or 3K Plain Or Twill | Material: | 100% Carbon Fiber |
Usage: | Windows Cleaning Waterfed Pole | Tolerance: | ±0.01mm |
Section: | 2/3/4/5/6/7 Sections/custom | Lock Types: | Flip Lock/ Twist Lock/ Straight Pull Lock |
Highlight: | 15m Carbon Fiber Telescopic Pole,20m Carbon Fiber Telescopic Pole,18m Carbon Fiber Telescopic Pole |
Product Description
15m, 18m, 20m Carbon Fiber Telescopic Pole Carbon Fiber Telescopic Areca Nut Harvesting Pole
Carbon fiber telescoping tubes nest within one another and slide effortlessly. They are ideal for creating adjustable poles, robotics, factory automation, or any other application where compact storage and long extension lengths are necessary. Additional clamping force in the collet can be obtained by sanding the tube to remove the epoxy ridges.
The Carbon Fiber Telescopic Poles come in a variety of sizes to help accommodate many different tasks.
Key Features of the Telescopic Poles include
Often used in place of aluminum for structural frames, machinery components, and robotics, these tubes are lighter in weight and almost as rigid. Carbon fiber is known for its use in the aerospace industry where a balance of weight and strength is vital. Thanks to these tubes being lightweight, they reduce wear and stress on motorized parts to extend the life of machinery.
Plain matte tubes have fibers that run in one direction, making them strong in the direction of the fibers. They resist bending across the fibers but will splinter and separate like string cheese when bent along the length of the fiber. Plain glossy tubes and checked tubes have layers with fibers that alternate in two directions, so they resist bending and crushing across the entire tube. They have more structural integrity compared to plain matte tubes.
Checked carbon fiber has the classic carbon-fiber look and is easy to machine—it won’t fray or splinter when cut. Glossy carbon fiber has a shiny finish that can be sanded to matte. Matte carbon fiber is ready to paint and won’t reflect light, making it ideal for photography applications.
Item Type | Carbon Fiber Telescoping Pole |
Material | 100%Carbon Fiber |
Color | Silver, Black, Blue, Green, Golden, Red, or customized. |
Size | Outer Diameter:1mm/1.5mm/2mm/2.5mm/3mm/customized Wall Thickness: 0.5/0.8/1.1/1.5/customized Length: Based on your requirements |
Lock Types | Flip Lock/ Twist Lock/ Straight Pull Lock |
Finish | Matt Twill/Matt Plain/Glossy Twill/Glossy Plain |
Application | Light poles, tripods, paddles, fishing poles, robots, picking poles, detection poles, cleaning poles, rescue poles |
Fiber Specifications | 1K/3K/6K/12K |
Delivery time | 15-20 days after the sample is confirmed & down payment, or negotiated |
Deep process | CNC, drilling, milling, cutting, stamping, welding, bending, assembling, custom aluminum fabrication |
Tolerance | ±0.01mm |
OEM & ODM | Acceptable |
Packaging | standard export packaging or as discussed |
