Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Normal Corrugated Carton Packing for International Shipment Delivery Time : 7 working days after receiving Order Payment
Payment Terms : T/T, PayPal,Western Union , L/C Supply Ability : 1500pcs month
Place of Origin: China Brand Name: Tanku
Certification: SGS, ROHS Model Number: TM_340mm_410mm_2.5mm

Detail Information

Features: Strength And Light Weight Product: Carbon Fiber Plate
Thickness: 1.0MM 1.5MM 2.0MM 2.5MM 3.0MM 4.0MM 5.0MM Dimension: As Requested
Surface: Glossy/ Matte Weave: 3K Plain / 3K Twill / Unidirection
Tensile Strength: 3200Mpa Product Type: Carbon Fiber Board/ Panels
High Light:

Carbon Fiber Sheet 1.5MM

,

Glossy Carbon Fiber Plate Heat Resistant

,

Aerospace Grade 3K Carbon Fiber Plate

Product Description

Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade



The carbon fiber is aerospace-grade Unidirectional and Woven carbon fiber, pre-preg with a highly-toughened epoxy resin used to build jumbo jet airliners. It is cured at 350°F for 120 minutes at 100 psi. They are quasi-isotropic using 0, 90, and +/-45 degree layup for maximum strength, 28 layers thick with plain weave on the outside.





Our Carbon Fiber Panels are constructed with the same certified carbon fiber that is currently used in state of the art aircraft and sailing yachts. ?With the use of certified T-300 carbon fiber fabric all of our carbon fiber panels are made to the highest standards in both manufacture and material.



Carbon fiber panels have physical properties that are similar to steel. However, the stiffness of carbon fiber is superior to that of an equivalent piece of steel while also remaining much substantially lighter and is similar to plastic in weight. This gives the carbon fiber panels a much higher strength to weight ratio by comparison.



Product Feature:



100% 3K Carbon Fiber Strong Strength and Light Weight.
Perfect for any application including RC, drones, helicopters, etc.
The surface is cross grain, a nice surface without any glass fiber contents.
These carbon fiber sheets contain 100% carbon fiber imported from Japan.
It is especially applicable for Multicopter, Helicopter, and RC airplanes.



Product Application:



1. Aerospace, RC model parts Helicopters Model Drone, UAVS
2. Decoration parts for Car and jewelry
3. Manufacture fixtures and tooling
4. Industrial automation and robotics
5. Sports equipment
6. Musical instruments
7. Scientific Apparatus
8. Medical device
9. Others



Carbon Fiber Sheet Plate Specification:



Item Name

Thickness

Length & Width

Weave

Finish

SKU Code

N.W.

Regular MOQ

1st Order MOQ

Ship From

05005060, Full CF Plate, Plain Weave,6K, Matte, TT

5

500mm*600mm

Twill

Glossy

TG05005060PLTFCF3KTT

2.48

5

1

China factory

04005060, Full CF Plate, Plain Weave,5K, Matte, TT

4

500mm*600mm

Twill

Glossy

TG04005060PLTFCF3KTT

1.94

5

1

China factory

03005060, Full CF Plate, Plain Weave,4K, Matte, TT

3

500mm*600mm

Twill

Glossy

TG03005060PLTFCF3KTT

1.46

5

1

China factory

02505060, Full CF Plate, Plain Weave,3K, Matte, TT

2.5

500mm*600mm

Twill

Glossy

TG02505060PLTFCF3KTT

0

5

1

China factory

02005060, Full CF Plate, Plain Weave,3K, Matte, TT

2

500mm*600mm

Twill

Glossy

TG02005060PLTFCF3KTT

0.96

5

1

China factory

01505060, Full CF Plate, Plain Weave,3K, Matte, TT

1.5

500mm*600mm

Twill

Glossy

TG01505060PLTFCF3KTT

0.73

5

1

China factory

01005060, Full CF Plate, Plain Weave,3K, Matte, TT

1

500mm*600mm

Twill

Glossy

TG01005060PLTFCF3KTT

0.53

5

1

China factory



Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade 0Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade 1Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade 2Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade 3Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade 4

Heat Resistant 100% 3K Glossy Surface Carbon Fiber Plate - Aerospace Grade 5
