18m 60ft Retractable Extension Carbon Fiber Poles Adjustable Telescopic Tube

Minimum Order Quantity : 10 Sets Price : Negotiable
Packaging Details : 150*30*30cm/CTN, 10 Sets/CTN, Corrugated Carton for International Ocean Airlines shipping Delivery Time : 25 Days after Order Confirmation
Payment Terms : L/C, T/T, PayPal Supply Ability : 500 Sets/Month
Place of Origin: China Brand Name: 10M
Certification: SGS Model Number: 10M45FT

Detail Information

Tube Material: Extendable Carbon Fibre Poles Clamp Material: CFR Nylon, Aluminum
Usage: Windows Cleaning Waterfed Pole Color: Black Or Custom
Technology: Rolled-Wrapping Surface: 3K Plain 3K Twill Surface
Section: 2/3/4/5/6/7 Sections/custom Lock Type: Flip Cam Locking Device
High Light:

60ft Retractable Extension Pole

,

Extension Adjustable Telescopic Tube

,

Carbon Fiber Extendable Poles

Product Description

18m 60ft retractable extension pole adjustable telescopic tube extendable poles carbon fibre poles



Carbon fiber products produced by LIJIN use imported high-quality carbon fiber raw materials. LIJIN owns the complete production line from the carbon fiber filament to the final product. The carbon fiber we apply is woven at the same factory with the high-quality filament imported from Japan Toray.



The tensile strength of carbon fiber composite materials is 6 to 12 times that of steel and can reach 3000 Mpa, and the comprehensive index of specific strength and specific modulus is the most prominent among the existing structure materials.



Specification

  • Length: Wholesale ultra-light telescopic carbon fiber extending pole for house cleaning
  • Type: 100% carbon fiber tube/poles; or fiberglass pole
  • Surface: UD Standard, 3K can be custom
  • Clamp: Flip/buckle locking is convenient to use

Carbon fiber is used for many applications due to its unique properties. The major advantages of carbon fiber over traditional materials like steel, aluminum, wood and plastics include:

  • High stiffness and strength
  • Lightweight
  • Corrosion resistance
  • X-ray transparency
  • Low CTE (Coefficient of Thermal Expansion)
  • Chemical resistivity
  • Thermal and electrical conductivity

Detailed Size:



Warning section 100mm Lgth
Top section(smallest) 22OD18ID
Section2 26OD2260ID
Section3 3030OD2690ID
Section4 3440OD31ID
Section5 3880OD3520ID
Section6 4330OD3970ID



CHARACTERISTICS:
• Extended total length: 5000mm. (Tolerance ± 10mm.)
• Total length collected: 1360mm. (Tolerance ± 10mm.)
• Outside diameter of the larger tube: 31mm. (Tolerance ± 0.2mm.)
• Wall of the tubes: 1mm. (Tolerance ± 0.2mm.)
• Total weight: 812gr. (Tolerance ± 50gr.)
• Fiber: carbon 3K 200 gr / m2 Fabric Twill 2x2 (Twill)
• Resin: Epoxy
• Orientation of the fibers: Bidirectional



18m 60ft Retractable Extension  Carbon Fiber Poles Adjustable Telescopic Tube 018m 60ft Retractable Extension  Carbon Fiber Poles Adjustable Telescopic Tube 118m 60ft Retractable Extension  Carbon Fiber Poles Adjustable Telescopic Tube 218m 60ft Retractable Extension  Carbon Fiber Poles Adjustable Telescopic Tube 3
