Flexibility 100% Real Carbon Tubes 3K Wrapped Carbon Fiber Composite Tube
Contact Person : Terry.Chang, Grace Gu
Phone Number : +86-13681832139
WhatsApp : +8619537611058
Minimum Order Quantity : | Negotiable | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Normal Corrugated Carton Packing for International Shipment | Delivery Time : | 7 working days after receiving Order Pay |
Payment Terms : | T/T, Western Union, L/C | Supply Ability : | 1500pcs month |
Place of Origin: | China | Brand Name: | Tanku |
---|---|---|---|
Certification: | SGS, ROHS | Model Number: | OEM |
Detail Information |
|||
Product Name: | Matte Finish Carbon Fiber Tube | Material: | 100% Real Carbon Fiber Composite, T300 Carbon Fibers |
---|---|---|---|
Different Densities: | 1.5g/cm^3 | Working Temperature: | -50-150℃ |
Application: | Multi-Function, UAV/RC Toys/Building/Sports, Etc. | Tolerance: | ±0.1mm |
Surface Treatment: | Customized | Shape: | Round |
High Light: | Carbon Fiber Rod Low Thermal Expansion,Matte Finish Carbon Fiber Round Tube,High Hardness Multifunction Carbon Fiber Pipe |
Product Description
High Hardness Low Thermal Expansion Matte Finish Carbon Fiber Tube
Carbon fiber is replacing aluminum in an increasing variety of applications and has been doing so for the last few decades. These fibers are known for their exceptional strength and rigidity and are also extremely lightweight.
The specific properties of carbon fiber tubes make them a valuable component in various industries, providing high-performance solutions where strength, rigidity, and lightweight properties are vital.
The round carbon fiber tube's properties make it a valuable component in a wide range of industries, offering high-performance solutions where strength, rigidity, and lightweight properties are vital. The circular cross-section of these tubes allows for an even distribution of forces, making them an excellent choice for various structural applications.
It's important to note that while the matte finish adds distinct visual appeal and some practical advantages, it does not significantly affect the inherent mechanical properties of the carbon fiber tube. If you are considering using matte finish carbon fiber tubes for a specific application, it is advisable to ensure that the mechanical and functional requirements are also met, in addition to the desired visual characteristics.
Application:
- Radio control models, radio control hobbies, (car, toys, plane, truck, helicopter, etc)
- Sports equipment: golf shaft, skiing pole, Arrow shaft, hiking pole, kite support, fishing pole, etc
- Aerospace Instrument & Interior Supports
- Industrial automation and robotics arms
- Musical instruments
- Energy, wind machines
- Light aircraft tubing
Key Features
What We Manufacture
Material | Carbon Fiber Tube |
Shape | Round |
Technology | Roll-wrapped or pultrusion |
Dimension | The existing inner diameter of the mold is 4mm-50mm with a length of 1m. |
Customizable size: The maximum diameter can be 200mm, the longest can be 3m. | |
Surface | Black glossy/matte surface/painted |
Glossy 3k weave/matte 3k weave | |
Color metal wire weave | |
Feature | lightweight, high strength |
Working Temperature | Usually, -30-120 degrees, if special requirement, please let us know. |
Place Of Origin | China |
Function | Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products |
Tolerance | Diameter Tolerance: +/-0.1mm |
Length Tolerance | +/-1mm |
